China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

Name: China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
Brand: Beyde Trading Co.,Ltd
SKU: 500/1+6
Availability: InStock

Rincian produk

Tempat asal: CINA

Nama merek: Beyde

Sertifikasi: CE

Nomor model: 500/1+6

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 set

Kemasan rincian: Pengemasan wadah pengaman

Waktu pengiriman: 90 hari

Syarat-syarat pembayaran: L/c, d/a, d/p, t/t

Menyediakan kemampuan: 200 set/tahun

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk

Rincian produk

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                500mm tubular stranding machine, big bearing tubular stranding machine, China manufacture tubular stranding machine


Penggunaan:	Terdampar	Warna:	Menurut persyaratan pelanggan
Nama:	Mesin Terdampar Tubular	Aplikasi:	baja, aluminium, kawat baja yang terdampar
Bahan kawat:	Baja, tembaga	Gelendong pembayaran pusat:	PN400-PN630
Ukuran gelendong pengambil:	PND800-PND1600	Diameter kawat telanjang maksimum:	4mm
Jaminan:	12 bulan

Penggunaan:	Terdampar
Warna:	Menurut persyaratan pelanggan
Nama:	Mesin Terdampar Tubular
Aplikasi:	baja, aluminium, kawat baja yang terdampar
Bahan kawat:	Baja, tembaga
Gelendong pembayaran pusat:	PN400-PN630
Ukuran gelendong pengambil:	PND800-PND1600
Diameter kawat telanjang maksimum:	4mm
Jaminan:	12 bulan

Deskripsi Produk

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.

Model		400	500	630
Inlet wire Dia.(mm)	Conductor	1.5-3.5	1.8-4.0	2.0-5.0
	Steel	1.0-2.5	1.5-3.0	1.8-4.0
	Cores	1.2-3.5	1.5-5.0
Frame rotation speed(r/min)		700	600	400
Stranding Pitch(mm)		41-312	44-334
Linear Speed(m/min)		27-205.3	22-166.85	14-108.9
Capstan Dia.(mm)		800+1000	1000+1200	1000+1250
Size of tak-up bobbin		PN1250	PN1600	PN1600

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 0

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 1

FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
